LED Canopy Light | Adj Watt 100W/120W/150W | 21000 Lumens | Adj CCT 4000K/5000K/5700K | 120V-277V

LED Canopy Light | Adj Watt 100W/120W/150W | 21000 Lumens | Adj CCT 4000K/5000K/5700K | 120V-277V

IP65 - UL & DLC Listed - 5 Year Warranty

  • Up to 140 lumens per watt
  • 0-10V Dimmable
  • Beam Angle 120º Degree
  • Built-in 10KV Surge Protector
  • 3/4” Pipe mount
  • Die cast Aluminum white housing
  • IP65 Rated
  • Input Voltage 120-277VAC
  • UL & DLC Listed
  • 5 Year warranty
Nothing But LEDs Canopy Light Luminaire offers exceptional performance, efficiency and a unique design. Features such as high lumens per watt, outstanding efficacy and field serviceability, make it an ideal commercial canopy solution. The contract...
View Important Details
SKU: 1560782
Regular price $134.99 ea.
Sale price $134.99 ea. Regular price ea.
Call for Bulk Order
800-414-8919
Product Details
  • Up to 140 lumens per watt
  • 0-10V Dimmable
  • Beam Angle 120º Degree
  • Built-in 10KV Surge Protector
  • 3/4” Pipe mount
  • Die cast Aluminum white housing
  • IP65 Rated
  • Input Voltage 120-277VAC
  • UL & DLC Listed
  • 5 Year warranty

Nothing But LEDs Canopy Light Luminaire offers exceptional performance, efficiency and a unique design. Features such as high lumens per watt, outstanding efficacy and field serviceability, make it an ideal commercial canopy solution. The contractor-friendly LED canopy Light luminaire includes fasteners and a locking collar, making installation easy, secure and water-tight. It can be surface mounted easily from below the canopy deck and also has the ability to be pendant mounted.

  • Up to 140 lumens per watt
  • 0-10V Dimmable
  • Beam Angle 120º Degree
  • Built-in 10KV Surge Protector
  • 3/4” Pipe mount
  • Die cast Aluminum white housing
  • IP65 Rated
  • Input Voltage 120-277VAC
  • UL & DLC Listed
  • 5 Year warranty
General Performance
Description Value
  • Model #
  • Wattage Adjustable
  • Lumen
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • Beam Angle
  • Diffuser Type
  • CP05-150L-CS-3CCT
  • 100W / 120W / 150W
  • Max 21000LM
  • Up to 140LM/W
  • 4000K / 5000K / 5700K
  • >80
  • 120°Degree
  • PC Lens
Electrical
Description Value
  • Input Voltage
  • Frequency
  • THD
  • Dimming
  • Power Factor
  • Driver Brand
  • Driver Model
  • Driver Surge Protection
  • Flicker Percent
  • 120-277Vac
  • 50/60Hz
  • ≤20%
  • 0-10V
  • ≥0.9
  • Sosen
  • SS-160NH-E Series
  • L/N 6KV, L/N-P 6KV
  • <5%
Physical
Description Value
  • Operating Temperature
  • Operating Humidity
  • Storage Temperature
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED QTY
  • Housing
  • Housing Color
  • -40°C To 45°C
  • 10% - 90% RH
  • -40°C TO 90°C
  • 5% - 95% RH
  • Lumileds
  • SMD2835
  • 520 Pcs
  • ADC12 Aluminum Die Casting
  • White
