LED Linear High Bay | 320 Watt | 38400 Lumens | 6500K | 120-277Vac

LED Linear High Bay | 320 Watt | 38400 Lumens | 6500K | 120-277Vac

4ft - White Housing - UL Listed - 5 Year Warranty

  • Ultra-thin Sleek Design
  • Galvanized Steel with white paint
  • PMMA Lens with customized cloud diffuser
  • 1-10V Dimmable
  • 320W with 38400 delivered lumens
  • Standard Chain mount included
  • Universal 120-277Vac
  • UL Listed
  • 5 years warranty.
The LED Linear High Bay from Nothing But LED’s is the most innovative and revolutionary product of 2023. Linear High Bay improves focus and concentration by providing uniform illumination. Its delivered lumens of 38400 are ideal for ceiling height...
View Important Details
SKU: 1540303-1
$129.99 ea.
$129.99 ea. ea.
Call for Bulk Order
800-414-8919
Product Details
  • Ultra-thin Sleek Design
  • Galvanized Steel with white paint
  • PMMA Lens with customized cloud diffuser
  • 1-10V Dimmable
  • 320W with 38400 delivered lumens
  • Standard Chain mount included
  • Universal 120-277Vac
  • UL Listed
  • 5 years warranty.

The LED Linear High Bay from Nothing But LED’s is the most innovative and revolutionary product of 2023. Linear High Bay improves focus and concentration by providing uniform illumination. Its delivered lumens of 38400 are ideal for ceiling heights of up to 20 feet. Linear High Bay Luminaires are easy to install and come with a variety of mounting options. Linear High Bay luminaires are ideal for warehouses and high-end retail outlets. This UL certified High Bay has a 5-year warranty.

  • Ultra-thin Sleek Design
  • Galvanized Steel with white paint
  • PMMA Lens with customized cloud diffuser
  • 1-10V Dimmable
  • 320W with 38400 delivered lumens
  • Standard Chain mount included
  • Universal 120-277Vac
  • UL Listed
  • 5 years warranty.
Spec Sheet and Reports
General Performance
Description Value
  • Model #
  • Wattage
  • Lumen
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • Beam Angle
  • Diffuser Type
  • BLT-PHB07-320WBFW1A1-WH65
  • 320W
  • 38400LM
  • Up to 120LM/W
  • 6500K
  • >80
  • 90° Degree
  • PMMA Lens
Electrical
Description Value
  • Input Voltage
  • Frequency
  • Dimming
  • Power Factor
  • Driver Surge Protection
  • Flicker Percent
  • 120-277Vac
  • 50/60Hz
  • 1-10V
  • ≥0.9
  • L-N : 2KV. L/N-PE :4KV
  • No Flickering
Physical
Description Value
  • Operating Temperature
  • Operating Humidity
  • Storage Temperature
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED QTY
  • Housing
  • Housing Color
  • 40°C To 50°C
  • 20%-90%RH
  • -40°C To 80°C
  • 10% - 95% RH
  • Lumileds
  • SMD 2835 (0.5W)
  • 1215 PCS
  • Lamp Body Material Galvanized Sheet
  • White
