LED Area Light | Adj Watt 100W/150W/200W/240W/300W | 48000Lm | Adj CCT 3K/4K/5K | 120-347V

LED Area Light | Adj Watt 100W/150W/200W/240W/300W | 48000Lm | Adj CCT 3K/4K/5K | 120-347V

Universal & Yoke Mount Included - UL & DLC Listed - 7 Year Warranty

  • Up to 160 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • Adjustable Beam Angle by click of a button Type III / Type IV / Type V
  • Optional Screw-in Photocell
  • Universal & Yoke mount included
  • Built-in 20KV Surge Protector
  • 0-10V Dimmable
  • Bronze Housing
  • Input Voltage 120-347VAC
  • UL & DLC Listed
  • 7-Year Warranty
LED area light The Most Feature-Rich Fixture in the World. The LED area light is a groundbreaking innovation in outdoor lighting and a top contender for Most Innovative Product of the Year at LightFair International (LFI) 2025. Engineered for unmatched flexibility, performance, and simplicity, LED area light consolidates what would normally require more than 90 SKUs into a single, all-in-one fixture—making it the most feature-rich LED area lig...
View Important Details
SKU: 1570006-1
$309.99 ea.
$309.99 ea. ea.
Call for Bulk Order
800-414-8919
Spec Logo Spec Logo Spec Logo
Product Details
  • Up to 160 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • Adjustable Beam Angle by click of a button Type III / Type IV / Type V
  • Optional Screw-in Photocell
  • Universal & Yoke mount included
  • Built-in 20KV Surge Protector
  • 0-10V Dimmable
  • Bronze Housing
  • Input Voltage 120-347VAC
  • UL & DLC Listed
  • 7-Year Warranty
LED area light The Most Feature-Rich Fixture in the World. The LED area light is a groundbreaking innovation in outdoor lighting and a top contender for Most Innovative Product of the Year at LightFair International (LFI) 2025. Engineered for unmatched flexibility, performance, and simplicity, LED area light consolidates what would normally require more than 90 SKUs into a single, all-in-one fixture—making it the most feature-rich LED area light on the market today. LED area light combines adjustable wattage (100W, 150W, 200W, 240W, 300W) with selectable CCT (3000K, 4000K, 5000K), allowing complete customization on-site. Its beam angle adjustability—Type III, Type IV, and Type V—is uniquely achieved at the push of a button, a feature not found in any other fixture in the world. No tools. No lens swaps. Just quick, effortless adjustments. With an ultra-high efficiency of 160 lumens per watt, built-in 10kV surge protection, and universal input voltage (120–347V), LED area light is built to perform in any condition. It’s also smart control ready, with a plug-and-play receptacle that supports Haisen smart systems for advanced lighting control and energy savings. Every LED area light comes ready to install with both universal and yoke mounting brackets included in the box, eliminating the need for additional accessories. Whether you’re illuminating a parking lot, roadway, building facade, or using it as a floodlight or security light, LED area light adapts to virtually any application. Distributors can now stock one fixture instead of dozens, saving inventory space, time, and money. From street lighting to area and flood lighting, the LED area light is your all-in-one solution—truly the most versatile and complete LED fixture ever created.
  • Up to 160 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • Adjustable Beam Angle by click of a button Type III / Type IV / Type V
  • Optional Screw-in Photocell
  • Universal & Yoke mount included
  • Built-in 20KV Surge Protector
  • 0-10V Dimmable
  • Bronze Housing
  • Input Voltage 120-347VAC
  • UL & DLC Listed
  • 7-Year Warranty

Spec Sheet LM79 ReportLM80 ReportIES File

Spec Sheet and Reports
General Performance
Description Value
  • Adj Watt
  • Max Lumens
  • Lumen Efficacy
  • CCT
  • CRI (Ra)
  • Distribution Pattern
  • Beam Angle
  • 100W/150W/200W/240W/300W
  • 48000Lm
  • Up to 160Lm/W
  • 3K/4K/5K
  • >80
  • Type III TypeIV Type V
  • 155*70° 155*120° 155*145°
  • Surge Protector
  • THD
  • Operating Temperature
  • Storage Temperature
  • Operating Humidity
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED QTY
  • Housing Material
  • Housing Color
  • Built-in 20KV Surge Protector
  • ≤20%
  • -40°C TO 50°C
  • -40°C TO 90°C
  • 10％ - 90％ RH
  • 5％ - 95％ RH
  • Lumileds
  • 2835
  • 936 Pcs
  • Die-cast aluminum
  • Bronze
Electrical
Description Value
  • Input Voltage
  • Frequency
  • Dimming
  • PF
  • Flicker Percent
  • Driver Brand
  • Driver Model
  • 120-347VAC
  • 50/60Hz
  • 0-10V Dimmable
  • <0.9
  • ≥5%
  • SOSEN
  • SS-320NM-A260BHB
Frequently Asked Questions
What wattage options are available in this adjustable LED area light?

This LED area light doesn’t come in just one power level. You can adjust it to 100 W, 150 W, 200 W, 240 W, or 300 W right on the fixture itself. That means one light can serve many applications without buying separate models.

Can the color temperature (3000K, 4000K, 5000K) be changed after installation?

Yes. The color temperature is field‑adjustable, so you can switch between 3000 K (warm white), 4000 K (neutral white), and 5000 K (cool white) even after the light is installed. You don’t need a different fixture for each color temperature, just choose what works best for your space on site.

How do I switch between Type III, Type IV, and Type V beam distributions?

This light makes beam pattern changes easy. With just the push of a button, you can toggle between Type III (wide roadway/area), Type IV (forward throw), and Type V (even all‑around coverage) beam distributions. There’s no need to swap lenses or use tools — it’s built into the light’s design.

What mounting options are included with this LED area light fixture?

Each light comes ready to install with two mounting choices in the box:

  • Universal mount bracket
  • Yoke mount bracket

This gives you flexibility to mount the light on poles, walls, arms, or other surfaces without buying extra hardware.

Is this LED area light compatible with photocells and smart lighting controls?

Yes. The fixture is compatible with optional screw‑in photocells (sold separately), so it can automatically turn on/off with daylight. It’s also smart lighting ready. It has a receptacle to support plug‑and‑play smart controls like Haisen systems for advanced scheduling and energy savings.

Is the fixture UL & DLC listed and eligible for utility rebates?

Absolutely. This LED area light is both UL Listed and DLC Listed, which means it meets strict safety and performance standards. Because of these certifications, it is eligible for many utility and energy‑efficiency rebate programs, helping you save on cost when you replace older lighting with this energy‑efficient model.

.
