LED Linkable Strip Fixture | Adj Watt 20W/30W/40W | 5584 Lumens | Adj CCT 3000K/4000K/5000K/5700K/6500K | 120-277Vac

LED Linkable Strip Fixture | Adj Watt 20W/30W/40W | 5584 Lumens | Adj CCT 3000K/4000K/5000K/5700K/6500K | 120-277Vac

4ft | UL & DLC Listed | 5 Year Warranty

  • Up to 140 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 4’ Linkable up to 11 Pcs
  • 0-10V Dimmable
  • White housing
  • Surface mount Included
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
The LED Strip Light from Nothing But LEDs offers a high-performance, energy-efficient lighting solution ideal for a wide range of commercial applications. It is designed to replace traditional low-voltage, halogen, or fluorescent fixtures with an ...
View Important Details
SKU: 1570023
Regular price $39.99 ea.
Sale price $39.99 ea. Regular price ea.

Sold as a Pack 4
for $159.96

Call for Bulk Order
800-414-8919
Product Details
  • Up to 140 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 4’ Linkable up to 11 Pcs
  • 0-10V Dimmable
  • White housing
  • Surface mount Included
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty

The LED Strip Light from Nothing But LEDs offers a high-performance, energy-efficient lighting solution ideal for a wide range of commercial applications. It is designed to replace traditional low-voltage, halogen, or fluorescent fixtures with an advanced LED option that ensures maximum brightness and long-lasting reliability. Available in two models, the Standard Model and the Quick Connect Model, this fixture provides flexibility for various installation needs. The Standard Model requires traditional wiring and brackets to connect multiple fixtures, allowing for continuous lighting setups. In contrast, the Quick Connect Model, introduced in 2025, features built-in male and female connectors, enabling quick, tool-free installation without additional wiring.

  • Up to 140 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 4’ Linkable up to 11 Pcs
  • 0-10V Dimmable
  • White housing
  • Surface mount Included
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
General Performance
Description Value
  • Model #
  • Adjustable Watt
  • Max Lumens
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • BLT-LA04A-40W4FTBTL1A1-WH30/40/50/57/65
  • 20W / 30W / 40W
  • 5584Lm
  • Up to 140LM/W
  • 3000K / 4000K / 5000K / 5700K / 6500K
  • >80
Electrical
Description Value
  • Beam Angle
  • Input Voltage
  • Diffuser Type
  • Dimming
  • Power Factor
  • THD (Tolerance : +5%)
  • Flicker Percent
  • Driver Brand
  • Driver Model
  • Driver Surge Protection
  • 130°
  • 120-277Vac, 50/60Hz
  • PC Lens (Round)
  • 0-10V Dimmable
  • ≥0.9
  • ≤20%
  • <5%
  • BECKY
  • BQ-40L3-X-Y-Z
  • L/N-PE: 2kV, L-N: 1kV
Physical
Description Value
  • Operating Temperature
  • Operating Temperature
  • Operating Temperature
  • Operating Humidity
  • Storage Temperature
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED Qty.
  • Housing Material
  • -35C - +45C
  • With Sensor: -20C TO 45C
  • With Emergency Power Supply: 0C TO 40C
  • 20% - 90% RH-20°C to 80°C
  • -20°C to 80°C
  • 10% - 95% RH
  • Lumileds
  • SMD2835
  • 300 PCS
  • IRON
