LED Parking Garage Light | Adj Watt 20W/40W/60W/70W/80W | 12000 Lumens | Adj CCT 3000K/4000K/5000K | 120-277V

LED Parking Garage Light | Adj Watt 20W/40W/60W/70W/80W | 12000 Lumens | Adj CCT 3000K/4000K/5000K | 120-277V

UL & DLC Listed - 5 Year Warranty

  • Up to 150 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 0-10V Dimmable
  • Built-in Photocell ON/OFF switch
  • Sensor ON/DIM to 10%/OFF switch
  • 145° Beam Angle
  • Bronze housing
  • Input voltage 120-277V
  • UL & DLC listed
  • 5-year warranty
The LED Parking Garage Light from Nothing But LEDs offers unparalleled performance and versatility, making it the perfect solution for parking garages and large commercial spaces. The 2025 model features adjustable wattage and CCT options, allowing for full customization to meet your lighting needs. With up to 150 lumens per watt, it provides bright, energy-efficient illumination, while the 145° beam angle ensures wide coverage. Feature-rich a...
View Important Details
SKU: 1570030
$77.99 ea.
$77.99 ea. ea.
Call for Bulk Order
800-414-8919
Spec Logo Spec Logo Spec Logo
Product Details
  • Up to 150 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 0-10V Dimmable
  • Built-in Photocell ON/OFF switch
  • Sensor ON/DIM to 10%/OFF switch
  • 145° Beam Angle
  • Bronze housing
  • Input voltage 120-277V
  • UL & DLC listed
  • 5-year warranty

The LED Parking Garage Light from Nothing But LEDs offers unparalleled performance and versatility, making it the perfect solution for parking garages and large commercial spaces. The 2025 model features adjustable wattage and CCT options, allowing for full customization to meet your lighting needs. With up to 150 lumens per watt, it provides bright, energy-efficient illumination, while the 145° beam angle ensures wide coverage. Feature-rich and designed for maximum convenience, the fixture comes equipped with a photocell ON/OFF switch and a microwave motion sensor, enabling automatic adjustments based on ambient light and motion, reducing energy consumption. The light can also be easily turned on and off, offering complete control over your lighting environment. Additionally, the 0-10V dimmable capability allows for precise lighting adjustments to further enhance energy efficiency and ambiance. Built with rugged bronze housing and an IP65 rating, this fixture is durable, weather-resistant, and ideal for any environment, delivering long-lasting performance for years to come.

  • Up to 150 lm/W
  • Adjustable wattage
  • Adjustable CCT
  • 0-10V Dimmable
  • Built-in Photocell ON/OFF switch
  • Sensor ON/DIM to 10% OFF switch
  • 145° Beam Angle
  • Bronze housing
  • Input voltage 120-277V
  • UL & DLC listed
  • 5-year warranty
Spec Sheet and Reports
General Performance
Description Value

  • Adjustable Watt
  • Max Lumens
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • Light Spread
  • Diffuser Type

  • 20W / 40W/ 60W / 70W / 80W
  • 12000Lm
  • Up to 150LM/W
  • 3000K / 4000K / 5000K
  • >80
  • 145°
  • Polycarbonate Lens
  • Operating Temperature
  • LED Type
  • Construction
  • -40°C to +45°C
  • SMD2835
  • Die-cast Aluminum
Electrical
Description Value
  • Input Voltage
  • Frequency
  • Dimming
  • Power Factor
  • Driver Surge Protection
  • THD
  • 120-277 Vac
  • 50/60Hz
  • 0-10V
  • ≥0.90
  • L/N 6KV, L/N-P 6KV
  • <20%
Frequently Asked Questions
How do adjustable wattage and CCT settings help customize lighting for parking garages?

The adjustable wattage lets you choose how bright the fixture runs. Lower settings like 20 W or 40 W use less energy for small areas or low-traffic times, while higher settings like 70 W or 80 W deliver stronger illumination for larger garages or areas needing more visibility. Adjustable CCT lets you set the color temperature — warm (3000K) for a softer feel, neutral (4000K) for general lighting, or cool (5000K) for clearer visibility. Together, these adjustments help tailor the light to the height, size, and use of each garage space.

What benefits does the 145° beam angle provide for wide, low-ceiling spaces?

The 145° beam angle spreads light broadly across a wide area rather than concentrating it in a narrow spot. In parking garages with low ceilings and open layouts, that wide spread helps cover more surface area with fewer dark spots, improves uniformity, and reduces the number of fixtures needed to light the entire space.

How does the built-in photocell ON/OFF switch improve energy efficiency?

The built-in photocell with an ON/OFF switch senses ambient light and automatically turns the fixture on at dusk and off at dawn. When daylight is sufficient, the light stays off, saving energy and reducing unnecessary run time. The ON/OFF switch also lets you disable the photocell if you choose manual control or tie it into other control systems.

What is the function of the sensor ON/DIM to 10%/OFF control mode?

 In sensor ON/DIM to 10%/OFF mode, the fixture responds to motion in its range. When it detects movement, the garage light runs at full brightness. When no movement is present, it dims to 10% instead of turning fully off. This keeps a low level of illumination for safety while saving energy. If needed, the light can also be set to turn completely off when no motion is detected.

How does 0–10V dimming support lighting control in commercial garages?

0–10V dimming lets the light connect to dimming controls, building automation, and advanced lighting control systems. You can schedule dimming levels during off-peak hours, adjust light intensity based on time or occupancy, and integrate with other systems to lower energy use without losing needed visibility.

What makes this parking garage light suitable for long-term, high-use installations?

This fixture is built for tough, frequent use. It is IP65 rated, so it resists dust and moisture, and it is UL & DLC listed, which means it meets recognized safety and energy-efficiency standards. Durable construction and long LED life mean fewer replacements and lower maintenance costs. The flexible control options (photocell, dimming, sensor modes) help reduce energy use while delivering reliable, consistent illumination in high-traffic or 24/7 garage environments.

.
