LED Petroleum Canopy Light 150W 18750lm 5700K 120V–277V White Housing IP65 UL DLC Listed

LED Petroleum Canopy Light | 150 Watt | 22290 Lumens | 5700K | 120V-277V

IP65 | UL & DLC Listed | 5 Year Warranty

  • Up to 146 lm/W
  • 150 Watt
  • 5700K CCT
  • 0-10V Dimmable
  • 120º Beam Angle
  • Built-in 10KV surge protector
  • Direct surface or recessed mount
  • White housing
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
Nothing But LED's Canopy Light Luminaire offers exceptional performance, efficiency, and a unique design. Features such as high lumens per watt, outstanding efficacy, and field serviceability make it an ideal commercial canopy solution. The contractor-friendly LED canopy light luminaire includes fasteners and a locking collar, making installation easy, secure, and water-tight. It can be surface mounted easily from below the canopy deck and als...
View Important Details
SKU: 1550386
$94.99 ea.
$94.99 ea. ea.
Call for Bulk Order
800-414-8919
Spec Logo Spec Logo Spec Logo
Product Details
  • Up to 146 lm/W
  • 150 Watt
  • 5700K CCT
  • 0-10V Dimmable
  • 120º Beam Angle
  • Built-in 10KV surge protector
  • Direct surface or recessed mount
  • White housing
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty

Nothing But LED's Canopy Light Luminaire offers exceptional performance, efficiency, and a unique design. Features such as high lumens per watt, outstanding efficacy, and field serviceability make it an ideal commercial canopy solution. The contractor-friendly LED canopy light luminaire includes fasteners and a locking collar, making installation easy, secure, and water-tight. It can be surface mounted easily from below the canopy deck and also has the ability to be pendant mounted.

  • Up to 146 lm/W
  • 150 Watt
  • 5700K CCT
  • 0-10V Dimmable
  • 120º Beam Angle
  • Built-in 10KV surge protector
  • Direct surface or recessed mount
  • White housing
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
Spec Sheet and Reports
General Performance
Description Value
  • Model #
  • Wattage
  • Lumen
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • Beam Angle
  • Diffuser Type
  • BLT-CP06-150WWASA1-WH57
  • 150 Watt
  • 22290 LM
  • Up to 146LM/W
  • 5700K
  • >80
  • 120° Degree
  • PC Lens
  • Operating Temperature
  • Operating Humidity
  • Storage Temperature
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED QTY
  • Housing
  • -30°C - -50°C
  • -40°C - 80°C
  • 20％ - 90％ RH
  • 10% - 95% RH
  • LUMILEDS
  • SMD2835
  • 420 PCS
  • Die-cast Aluminum
Electrical
Description Value
  • Input Voltage
  • Frequency
  • THD
  • Dimming
  • Power Factor
  • Driver Brand
  • Driver Surge Protection
  • Flicker Percent
  • 120-277Vac
  • 50/60 Hz
  • ≤20%
  • 0-10V
  • ≥0.9
  • TOSMART
  • L-N 4KV,L/N-PE 4KV
  • ≤30%
Frequently Asked Questions
How does the 0‑10V dimming feature help optimize energy usage in commercial canopies?

The 0‑10V dimming feature lets you connect this canopy light to dimming controls or a building lighting system. When full brightness is not necessary, such as late at night or during slow business hours, you can reduce light output to save energy. This lowers electricity costs and reduces wear on the fixture without sacrificing safety when light is needed.

Can this luminaire be installed as both surface‑mounted and pendant‑mounted?

Yes. This canopy light is designed for installation flexibility. It can be mounted directly to the underside of a canopy or ceiling surface. With the right hardware, it can also be pendant‑mounted, giving you options to best fit the height and layout of your commercial space.

How does the built‑in 10KV surge protector protect the fixture from power surges?

The built‑in 10 KV surge protector guards the internal driver and electronics against sudden voltage spikes, such as those caused by lightning, utility switching, or unstable power sources. This protection reduces the risk of damage from electrical surges, helping the fixture last longer and maintain reliable performance in commercial environments.

What benefits does the 120° beam angle provide for canopy illumination?

The 120° beam angle spreads light widely and evenly across the area beneath the canopy. This broad distribution helps eliminate dark spots and ensures good visibility across fueling lanes, walkways, or service areas. It delivers smooth, uniform illumination that enhances safety and comfort for customers and staff.

How does the contractor‑friendly design simplify installation and maintenance?

This canopy light includes features such as a simple mounting bracket, accessible wiring compartment, and compatible hardware that reduce installation time and effort. The design lets technicians install, aim, and maintain the fixture without complex tools or extra parts, which saves labor and reduces overall project cost.

Why is UL & DLC listing important for commercial canopy lighting projects?

Being UL Listed means the product has been independently tested and meets recognized safety standards, giving confidence in its electrical performance and reliability. The DLC Listing indicates the fixture meets strict energy‑efficiency and performance criteria required for many utility rebate or incentive programs. Together, these certifications help ensure safety, efficiency, and potential cost savings through rebates on commercial lighting upgrades.

.
