LED Sign Tube | 15 Watt | 1687 Lumens | 6500K | 120V-277V | 30" | Clear | Double Sided | IP44 | ETL Listed | 5 Year Warranty - Nothing But LEDs

LED Sign Tube | 15 Watt | 1687 Lumens | 6500K | 120-277V

30" - ETL Listed - 5 Year Warranty

  • Input Voltage 120-277VAC
  • 50,000 hr lifespan
  • Type B/Double Ended Power
  • Integral LED Driver
  • IP44 Rated
  • 44 LED Qty
  • Environment Friendly
  • Non-flicker
  • Beam Angle 360°
  • ETL Listed
  • 5 Years Warranty
Our new and revolutionary Sign Tube offers significant energy efficiency and lifetime improvements over fluorescent lamps. Sign Tube lamps are installed by bypassing existing fluorescent ballasts and hard-wiring tombstone lamp holders directly to incoming AC power leads. Dual-ended bypass lamps eliminate the need to replace shunted tombstone lamp holders in existing fluorescent luminaires. An AC power cord is also provided for new installati...
View Important Details
SKU: 1520733
$32.99 ea.
$32.99 ea. ea.

Sold as a Pack 25
for $824.75

Call for Bulk Order
800-414-8919
Spec Logo Spec Logo Spec Logo
Product Details
  • Input Voltage 120-277VAC
  • 50,000 hr lifespan
  • Type B/Double Ended Power
  • Integral LED Driver
  • IP44 Rated
  • 44 LED Qty
  • Environment Friendly
  • Non-flicker
  • Beam Angle 360°
  • ETL Listed
  • 5 Years Warranty

Our new and revolutionary Sign Tube offers significant energy efficiency and lifetime improvements over fluorescent lamps. Sign Tube lamps are installed by bypassing existing fluorescent ballasts and hard-wiring tombstone lamp holders directly to incoming AC power leads. Dual-ended bypass lamps eliminate the need to replace shunted tombstone lamp holders in existing fluorescent luminaires. An AC power cord is also provided for new installations.

  • Input Voltage 120-277VAC
  • 50,000 hr lifespan
  • Type B/Double Ended Power
  • Integral LED Driver
  • IP44 Rated
  • 44 LED Qty
  • Environment Friendly
  • Non-flicker
  • Beam Angle 360°
  • ETL Listed
  • 5 Years Warranty
Spec Sheet and Reports
General Performance
Description Value

  • Watt
  • Color Temperature Adj.
  • Lumens
  • Lumen Efficacy
  • CRI (Ra)
  • Diffuser Type
  • Beam Angle

  • 15W
  • 6500K
  • Up to 1687LM
  • Up to 112LM/W
  • >80
  • Clear
  • 360°
  • DLC Type
  • Power Ends
  • Size
  • Lens
  • Type B
  • 2 Power Ends
  • 30”
  • Clear Cover
Electrical
Description Value
  • Input Voltage
  • PF
  • 120-277VAC 50/60Hz
  • ≥0.9
Frequently Asked Questions
How do I install this 15W LED Sign Tube?

Installation is easy! Simply bypass the old fluorescent ballasts and wire the tube directly to the AC power leads. This Type B ballast bypass design eliminates the need for external drivers or ballasts, making the process fast and efficient. The package also includes an AC power cord for new installations.

How bright is this LED Sign Tube?

The 15W LED Sign Tube delivers an impressive 1687 lumens, providing bright, clear illumination for signs and lightboxes. Its 6500K daylight white light enhances visibility, making it perfect for both indoor and outdoor signage.

Can this LED Sign Tube be used outdoors?

Yes, it is IP44 rated, which means it is dustproof and resistant to water splashes. This makes it perfect for covered outdoor signage, lightboxes, or installations exposed to moisture.

What is the lifespan of the LED Sign Tube?

This LED Sign Tube boasts a 50,000-hour lifespan, which is significantly longer than traditional fluorescent lighting. This extended lifespan helps you save on replacement costs and reduces maintenance efforts over time.

Does the LED Sign Tube come with a warranty?

Yes, it comes with a 5-year warranty, ensuring that you’re covered for a long time. You can have peace of mind knowing you’re investing in a durable, high-performance product.

.
