LED Wall Pack | Adj Watt 60W/90W/100W/120W | 18000 Lumens | Adj CCT 3000K/4000K/5000K | 120-277Vac

LED Wall Pack | Adj Watt 60W/90W/100W/120W | 18000 Lumens | Adj CCT 3000K/4000K/5000K | 120-277Vac

Built In Photocell - UL & DLC Listed - 5 Year Warranty

  • Up to 150 lm/W
  • Adjustable wattages
  • Adjustable CCT
  • Built-in photocell
  • 0-10V Dimmable
  • Bronze Housing
  • Durable glass diffuser
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
Nothing But LEDs (NBL) LED Wall Pack is a reliable outdoor lighting solution engineered for demanding commercial and industrial applications. It provides consistent, energy-efficient illumination for building perimeters, loading docks, warehouses, schools, and security areas where dependable lighting matters. With output reaching up to 150 lumens per watt, this fixture helps reduce energy consumption while maintaining strong brightness. It inc...
View Important Details
SKU: 1570231
$84.99 ea.
$84.99 ea. ea.
Call for Bulk Order
800-414-8919
Spec Logo Spec Logo Spec Logo
Product Details
  • Up to 150 lm/W
  • Adjustable wattages
  • Adjustable CCT
  • Built-in photocell
  • 0-10V Dimmable
  • Bronze Housing
  • Durable glass diffuser
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty

Nothing But LEDs (NBL) LED Wall Pack is a reliable outdoor lighting solution engineered for demanding commercial and industrial applications. It provides consistent, energy-efficient illumination for building perimeters, loading docks, warehouses, schools, and security areas where dependable lighting matters. With output reaching up to 150 lumens per watt, this fixture helps reduce energy consumption while maintaining strong brightness. It includes 4 adjustable wattage options and 3 selectable CCT settings, allowing easy on-site adjustments to match specific lighting requirements. An integrated dusk-to-dawn photocell enables automatic operation for added convenience and improved energy efficiency. Built for long term outdoor use, the fixture features a die-cast aluminum housing, durable glass lens, and IP65 rating to protect against dust, rain, and harsh weather conditions—ensuring dependable performance year-round.

  • Up to 150 lm/W
  • Adjustable wattages
  • Adjustable CCT
  • Built-in photocell
  • 0-10V Dimmable
  • Bronze Housing
  • Durable glass diffuser
  • Input Voltage 120-277VAC
  • UL & DLC listed
  • 5-year warranty
Spec Sheet and Reports
General Performance
Description Value
  • Adjustable Watt
  • Max Lumens
  • Lumen Efficacy
  • Color Temperature
  • CRI (Ra)
  • Light Spread
  • Diffuser Type
  • 60W / 90W / 100W / 120W
  • 18000
  • Up to 150LM/W
  • 3000K / 4000K / 5000K
  • >80
  • 100° (Type IV)
  • Glass Lens
  • Operating Temperature
  • Operating Humidity
  • Storage Temperature
  • Storage Humidity
  • LED Brand
  • LED Type
  • LED QTY
  • Construction
  • -40°C To 45°C
  • 5%RH To 95%RH
  • -40°C To 90°C
  • 5%RH To 95%RH
  • LUMILEDS
  • SMD2835
  • 624 Pcs
  • Die-cast Aluminum
Electrical
Description Value
  • Input Voltage
  • Frequency
  • Dimming
  • Power Factor
  • Driver Surge Protection
  • Driver Brand
  • Driver Model
  • Flicker Percent
  • 120-277Vac
  • 50/60Hz
  • 0-10V
  • ≥0.90
  • L/N 6KV, L/N-P 6KV
  • Sosen
  • SS-160NH
  • ≤30%
Frequently Asked Questions
How do the adjustable wattage options (60W, 90W, 100W, 120W) affect energy usage and light output?

The wattage settings let you choose how much light the fixture produces and how much energy it uses. The 60W setting uses the least energy and gives the lowest light output, which is good for smaller or low‑activity areas. 90W and 100W provide mid‑level brightness for general surface lighting. 120W gives the highest output for larger or high‑visibility areas. Being able to adjust the wattage lets you match the light level to the needs of the space and avoid using more power than necessary.

What is the difference between the 3000K, 4000K, and 5000K CCT settings?

The CCT settings change the color appearance of the light. 3000K produces a warmer tone that is more inviting and softer around building entrances and walkways. 4000K gives a neutral white that balances warmth and clarity for general exterior lighting. 5000K provides a cooler, daylight‑like color that enhances visibility and contrast, which can be useful for security areas, parking lot edges, and other outdoor spaces where clear detail is important.

Does the built‑in photocell provide automatic dusk‑to‑dawn operation?

 Yes. The built‑in photocell senses the level of natural light and automatically turns the wall pack on when it gets dark and off when daylight returns. This makes operation simple and helps save energy because the light only operates at night.

Is this LED wall pack compatible with 0–10V dimming controls?

Yes. This wall pack supports 0–10V dimming, so it can be connected to standard commercial dimming systems. That allows you to adjust the light level based on time of night, occupancy, or other control strategies.

Can this fixture operate on 120–277VAC electrical systems?

Yes. This wall pack is designed for universal operation on 120V to 277V power. That makes it compatible with most residential, commercial, and industrial electrical systems without needing additional transformers or power converters.

What types of commercial or industrial applications are best suited for this LED wall pack?

 This adjustable wall pack works well in many outdoor commercial and industrial settings. It is a good choice for building perimeters, loading docks, walkways, entrances, security lighting, parking lot edges, schools, hospitals, retail exteriors, warehouses, and other areas where reliable, customizable exterior lighting is needed.

.
